carbon steel sensor PTFE liner magmeter

24VDC and 220VAC, 3.6V lithium are available for transmitter of magnetic flowmeter. flange, tri-clamp, wafer, thread, insertion are optional in connection. we use mass method, pulse or comparison method to calibrate, each flow meter have calibration certificate together with goods. 5 points are calibrated for magnetic flowmeter. widely used for conductive liquids. electromagnetic flowmeter is composed by magnetic flow meter and pt1000 temeprature sensor, can calibrated on liquid test bench, standard accuracy is ¡À0.5%

Accuracy: ¡À0.5%
Repeatability: 0.17%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic

QTWG series electromagnetic flow meter is designed for demanding water and wastewater applications, and for use in hazardous areas and under harsh conditions. The flow meter features dual-compartment housing, up to three input/outputs, and accurate bidirectional measurement independent of pressure, density, temperature and viscosity.

Size:DN3-3000mm
Material:Carbon Steel SS304 S316
Dual Power:24V/220V
Nominal Pressure: 0.6-1.6Mpa(Max 42Mpa)
Accuracy: +/-0.5%(Standard)0.2% (Optional)
Liner: PTFE, Neoprene, Hard Rubber, EPDM, FEP, Polyurethane, PFA
Electrode Material:SUS316L,Hastelloy B,Hastelloy C,Titanium,Tantalum,Platinum-iridium
Output Signal: 4-20mA/Pulse
Ambient Temperature:-20~+60deg C

Q&T has sufficient flow meter stock,could guarantee fast delivery of battery operated electromagnetic flowmeter,battery flow meter is ideal when power supply is difficult or expensive. Accuracy: ¡À0.5% (Standard),¡À0.3% or ¡À0.2% (Optional); Liner: PTFE,Neoprene,Hard Rubber,EPDM,FEP,Polyurethane,PFA; Electrode: SUS316L,Hastelloy B,Hastelloy C,Titanium,Tantalum,Platinum-iridium; Structure: Integral,remote,submersible,ex-proof; Ambient Temperature: -20¡æ~+ 60¡æ; Ambient Humidity: 5-100% RH (relative humidity); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA/pulse (optional);

The converter of electromagnetic water meter adopts novel exci-tation mode with low power consumption, stable zero pointand high precision. The flow range can reach 150:1, and themeasurement is not affected by the changes of fluid density,
viscosity,temperature, pressure and conductivity
Full digital signal processing, stable measurement, high measurement accuracy Automatic two-way flow measurement, on-site instantaneous flow, positive and negative cumulative total display

Size DN50 to DN300 pipe line
Suitable for all conductive liquids
No moving parts
Near zero pressure drop
Wide range in electrode: SS316, Ti, HC, HB, Ta, Pt
Multi-choice in flange: DIN, GB, ANSI, JIS, EN, etc

Easy Setup
Minimal Straight Pipe
Forward or Reverse flow and Total
IP65,IP67 ,IP68 Rated (optional)
Virtually No Pressure Loss

With simple structure ,the flow meter is of high reliability without lining in the
measuring pipe .
The wide range of the nominal bore is suitable for all the pipe size between
DN2 and DN600.
Measurement is independent of fluid density ,viscosity ,humidity ,temperature
pressure and conductivity.

The QTLD electromagnetic flowmeter has no mechanical inertia, has a sensitive response, can measure instantaneous pulsating flow, and has good linearity. Therefore, the measurement signal can be directly converted into a standard signal output by a converter, which can be indicated locally or transmitted over a long distance.

Size: 1/8″-120″
Accuracy: ¡À0.5%
Repeatability: 0.17%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote

Q&T liquid flow meter including magnetic flow meter, electromagnetic flow meter, magmeter,which is designed to measure various conductive liquids. manufacturer of flow meters and level meters. Founded in 2005, certified ISO 9001:2015
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 ¦ÌS/cm, demineralized water > 20 ¦ÌS/cm

electromagnetic flowmeter can be used to measure the volume flow of conductive fluid in a closed pipeline. It is widely applied in the flow measurement and control in the fields of chemical and petroleum industry, metallurgy industry, water and wastewater, agriculture and irrigation, paper making, food and beverage industry and pharmaceutical industry, etc.
When the conductive fluid flows through the measuring tube of the sensor, the voltage signal in direct proportion to the average flow velocity of the fluid will be inducted on the electrodes. The signal is amplified and treated by the transmitter to realize various display functions.
Size: 1/8″-120″
Accuracy: ±0.5%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 μS/cm, demineralized water > 20 µS/cm
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Flange: ANSI, DIN, JIS, etc.

Electromagnetic water meter is using 16-bit embedded microprocessor, fast operation speed, high accuracy, programmable frequency low frequency rectangular wave excitation, improve the stability of flow measurement, and low power consumption. Full digital processing, strong anti-interference ability, reliable measurement, high accuracy, flow measurement range up to R400.
1.Sensor suitable:DN3~DN2800
2. Range of rate:0.01m/s~12m/s
3. Accuracy:Level 0.25
4. Low-frequency square wave or High-frequency Excitation
Excitation frequency:3.125Hz,6.25Hz,
12.5Hz,25Hz
5. Excitation Current:100mA ~500mA,Default 160mA or 250mA

3.6V battery powered magnetic flow meter universally applicable for conductive liquids, fully functional in remote areas without power grid,realize remote wireless measurement with GPRS,RS485,HART Accuracy: ¡À0.5% (Standard),¡À0.3% or ¡À0.2% (Optional); Liner: PTFE,Neoprene,Hard Rubber, EPDM,FEP,Polyurethane,PFA; Electrode: SUS316L, Hastelloy B, Hastelloy C,Titanium,Tantalum, Platinum-iridium; Ambient Temperature: -20¡æ~+ 60¡æ; Ambient Humidity: 5-100% RH (relative humidity); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA/pulse (optional);

Accuracy of mag flow meter is ¡À0.5% standard, ¡À0.2% is optional, magmeter is calibrated on ¡À0.2% accuracy calibration device. A flow transmitter energizes the coils which creates a magnetic field in the tube. A conductive fluid moving through this field generates an induced voltage at two electrodes in the tube. waste water flow meter can be compact type and remote type, standard cable length is 10m and max cable length is 120m.

Size: 1/8″-120″
Accuracy: ¡À0.5%
Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Velocity: 0.1~15 m/s

Q&T series Electromagnetic Flowmeter is designed and manufactured with the most advanced domestic and abroad technology, featuring high accuracy, reliability, good stability and long service life.

Size: 1/8″-120″
Accuracy: ±0.5%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 μS/cm, demineralized water > 20 µS/cm
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Flange: ANSI, DIN, JIS, etc.
Measuring tube: SS304
Function: High and low alarm, exciting alarm, empty pipe alarm, self-diagnosis

Electromagnetic water meter has excellent accuracy and flow rangeability. The meter is suitable for use on wide range of corrosive and aggressive range of conductive liquids.
1) Full-digital processing, high noise resistance and reliable measurement;
2) Flow measurement range up to R400
3) High definition LCD display with backlight.
4) RS485 and Wireless Function

Min size of insertion magnetic flowmeter is DN50 / 2″, it can be powered by AC/DC/3.6V lithium battery. insertion magnetic flowmeter can configure thread or flange ball valve to be hot-tapped, which allows sensor to be installed and retracted from process piping without shutting down the process.

Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Protection Grade: IP65 std, IP68 optional for remote
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Measuring tube: SS304

Q&T’s DC3.6V powered mag flow meter everyone will have well calibrated before leave factory, battery meter adopt pulse calibration, with weighing method, guarantee the 0.5% accuracy. Accuracy: ¡À0.5% (Standard),¡À0.3% or ¡À0.2% (Optional); Liner: PTFE,Neoprene,Hard Rubber,EPDM,FEP,Polyurethane,PFA; Electrode: SUS316L,Hastelloy B,Hastelloy C,Titanium,Tantalum,Platinum-iridium; Ambient Temperature: -20¡æ~+ 60¡æ; Ambient Humidity: 5-100% RH (relative humidity); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA/pulse (optional);

magmeter work based on the Faraday Law of electromagnetic induction. In a simplified description, the flow sensor contains two magnetic coils located on opposite sides of the tube. A flow transmitter energizes the coils which creates a magnetic field in the tube. A conductive fluid moving through this field generates an induced voltage at two electrodes in the tube. waste water flow meter can be compact type and remote type, standard cable length is 10m and max cable length is 120m.

Size: 1/8″-120″
Accuracy: ¡À0.5%
Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Velocity: 0.1~15 m/s

Mag flowmeter battery’s service life is 3 to 5 years, magnetic flow meter battery powered fulfills the customer demands to water application, revenue metering and irrigation. Nominal Pressure: 0.6-1.6MPa(2.5Mpa / 4.0Mpa /6.4Mpa…Max 42Mpa); Accuracy: ¡À0.5% (Standard), ¡À0.3% or ¡À0.2% (Optional); Measuring Range: Max 15m/s; Conductivity: >5us/cm; Protection Class: IP65(Standard),IP68(Optional for remote type); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional); Power Supply: Battery powered 3.6V,Battery powered 3.6V +DC24V(Optional);

Battery power magnetic flowmeter can be used in process measurement and control, leak detection, etc.Battery Insertion Magnetic flow meter usually for large diameter pipeline save cost. Size: DN10-DN2000; Nominal Pressure: 0.6-1.6MPa (2.5Mpa / 4.0Mpa /6.4Mpa…Max 42Mpa); Accuracy: ¡À0.5% (Standard),¡À0.3% or ¡À0.2% (Optional); Liner:PTFE,Neoprene,Hard Rubber,EPDM,FEP,Polyurethane, PFA; Electrode: SUS316L,Hastelloy B,Hastelloy C,Titanium,Tantalum,Platinum-iridium; Protection Class: IP65(Standard),IP68(Optional for remote type); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional);

There are no moving parts and no choke parts in the pipeline, and there is almost no additional pressure loss in the measurement. The measurement result has nothing to do with physical parameters such as velocity distribution, fluid pressure, temperature, density, viscosity, etc.
High-quality ABS, backlit LCD simultaneously displays
instantaneous flow and accumulated flow, instantaneous heat andaccumulated heat, flow rate, time and other data non-contactmeasurement, accurate measurement

Battery powered electromagnetic flowmeter is designed for calibration of flow meters under controlled and stable flow conditions.Battery flowmeters provide obstruction free flow measurement. Electrode: SUS316L,Hastelloy B,Hastelloy C, Titanium,Tantalum,Platinum-iridium; Protection Class: IP65(Standard),IP68(Optional for remote type); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional); Power Supply: Battery powered 3.6V,Battery powered 3.6V +DC24V(Optional); Power Consumption: 0.5W(Standard), 1.5W(with DC24V); Explosion Proof: ATEX

DC3.6V powered electromagnetic flowmeter satisfy water fee calculation with high accuracy, battery water meter is widely used in applications without power grid, can work with solar power supply. Accuracy: ¡À0.5% (Standard), ¡À0.3% or ¡À0.2% (Optional); Ambient Humidity: 5-100%RH (relative humidity); Protection Class: IP65(Standard), IP68(Optional for remote type); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional); Power Supply: Battery powered 3.6V,Battery powered 3.6V +DC24V(Optional); Power Consumption: 0.5W(Standard),1.5W(with DC24V);

electromagnetic flow meter is mainly used in pharmaceutical industry, in water treatment or in food production: If conductive media such as cooling water are added to a process, standard cable is 10m, max length is 120m, liquid flow meter is mainly used to measure beverage. waste water flow meter is usually installed for monitoring purposes, particularly in the context of dosing where the measuring flow meters must possess precise response times, and should also be easy to configure, otherwise incorrect dosing or insufficient repeatability will occur.

Accuracy: ¡À0.5%
Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s

Magnetic inductive flow meter is made by the flow transmitter and flow sensor; it is a kind of volumetric flow meter to detect liquid flow rate in a closed pipelines, and has no moving parts inside mag sensor, so little maintenance work is needed. The good point of inductive flow meter is that it can measure dirty liquid even will solids inside, such as slurry, grease, mud, also the .flow rate measurement is not affected by the liquid properties, such as temperature, viscosity ,and density.
Size: 1/8″-120″
Accuracy: ±0.5%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Flange: ANSI, DIN, JIS, etc.
Measuring tube: SS304

Electromagnetic water meters are designed for measurement of conductive liquids. mag meters have no moving parts and a PTFE/ rubber lining, they can handle applications involving wastewater, pulp, food, and slurries. Standard outputs include analog, frequency, and RS485 communications.
Specially used to measure conductive and non-conductive liquids mediums;
Providing OEM customized services and high-quality products;
Providing technical support, choosing flow meters according to different working conditions;

Battery-powered
electromagnetic water meter converter uses an ultra-low power circuit technology to design an efficient and reliable excitation circuit and signal processing using multi-stage amplification and anti-interference
processing to ensure that the converter has high reliability and stability and saves power supply costs.
With simple structure ,the flow meter is of high reliability without lining in the
measuring pipe .
The wide range of the nominal bore is suitable for all the pipe size between
DN2 and DN600.
Measurement is independent of fluid density ,viscosity ,humidity ,temperature
pressure and conductivity.

Magnetic heat meter is composed by transmitter, sensor and PT1000 temperature sensor, which can monitor flow and energy of hot water and cold water, standard configuration of flange and sensor shell is carbon steel, SS304 and SS316L are optional. the electromagnetic BTU meter has wide range of nominal diameters (DN3-3000), Independent of pressure, temperature, density and viscosity, magnetic energy meter is built-in grounding electrodes
Accuracy: ¡À0.5%
Repeatability: 0.17%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic

Battery powered magnetic flow meter is designed for calibration of flow meters under controlled and stable flow conditions.Battery meters provide obstruction free flow measurement. Electrode: SUS316L,Hastelloy B,Hastelloy C, Titanium,Tantalum,Platinum-iridium; Protection Class: IP65(Standard),IP68(Optional for remote type); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional); Power Supply: Battery powered 3.6V,Battery powered 3.6V +DC24V(Optional); Power Consumption: 0.5W(Standard), 1.5W(with DC24V); Explosion Proof: ATEX

Q&T Instrument is OEM with 17 year manufacturing experience. color and logo can be customized. magnetic flowmeter can be configuared SD card and bluetooth. standard display is LCD display, OLED display is optional.
Size: 1/8″-120″
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Measuring tube: SS304
